JUMO

04563371
JUMO 448986 Konduktiver 2-Elektroden Leitfähi

448986 4053877005759 00448986
auf Anfrage
je 1 ST
keine Verfügbarkeitsinformationen

Verpackungseinheiten

1 ST Menge übernehmen

Funktionen

Verkaufsdaten

Mindestbestellmenge 1 ST
Bestellschritt 1 ST

Beschreibung

This conductivity sensor has a cell constant of K=0.01 (for measuring ranges 0.05 to 20uS/cm) and a Pt100 measuring insert in two-wire circuit. It is installed via the PEI process connection G 1/2A. A attached cable of 5000 mm is available as electrical connection. The material of the electrode is stainless steel (1.4571). The insertion length is 63 mm. The operating temperature is -5 to +90 °C and the maximum compressive strength is 6 bar at 25 °C.

Merkmale

Verpackungseinheit 1
Gewicht 0,27
Gewichtseinheit KG
Gewichtbezugsmenge 1
Ausführung konduktiv
Kabellänge 5 m
Max. Druck 6 bar
Max. Temperatur 80 °C
Ausführung des elektrischen Anschlusses Kabel
Ausführung des Prozessanschlusses G 1/2 Zoll
Zellenkonstante 0,01
Werkstoff der Elektrode Edelstahl 316 Ti (1.4571)
Sensortyp Pt100
Einstecklänge 63 mm
Werkstoff des Prozessanschlusses sonstige
Kurzbeschreibung Conductive 2-electrode conductivity sensor 0.05 to 20 uS/cm, Pt100, G 1/2A
eClass 11.0 - Klasse 27209090
UNSPSC 14.0801 - Klasse 41111900
