Abbildung ähnlich
JUMO

04563389
JUMO 458083 Induktiver Leitfähigkeits-/Konzen

458083 4053877014645 00458083
auf Anfrage
je 1 ST
keine Verfügbarkeitsinformationen

Verpackungseinheiten

1 ST Menge übernehmen

Funktionen

Verkaufsdaten

Mindestbestellmenge 1 ST
Bestellschritt 1 ST

Beschreibung

This inductive conductivity/concentration and temperature transmitter with switching contracts and fixed mounted sensor has two freely programmable, analog outputs for conductivity and temperature as well as two potential-free contracts. It is possible to activate up to four ranges and temperature coefficients. The temperature compensation can be lineal, natural water or as an individual characteristic curve (learning function). Furthermore the instrument has a dilution control. This instrument has no display or keyboard and can therefore only be controlled via setup software. As a process connection the device has a union nut G 1 1/2 PVC and it has an internal temperature sensor. The power supply is provided by a power supply unit with DC 19...31 V.

Merkmale

Verpackungseinheit 1
Gewicht 1,79
Gewichtseinheit KG
Gewichtbezugsmenge 1
Ausführung induktiv
Max. Druck 10 bar
Max. Temperatur 60 °C
Ausführung des elektrischen Anschlusses sonstige
Ausführung des Prozessanschlusses sonstige
Zellenkonstante sonstige
Werkstoff der Elektrode sonstige
Sensortyp Pt1000
Einstecklänge 67 mm
Werkstoff des Prozessanschlusses sonstige
Kurzbeschreibung Inductive conductivity/concentration and temperature transmitter
eClass 11.0 - Klasse 27209090
UNSPSC 14.0801 - Klasse 41111900
