auf Anfrage
je 1 ST
keine Verfügbarkeitsinformationen
Verpackungseinheiten
| 1 ST | Menge übernehmen |
Funktionen
Verkaufsdaten
| Mindestbestellmenge | 1 ST |
| Bestellschritt | 1 ST |
Beschreibung
This conductivity sensor has a cell constant of K=0.01 (for measuring ranges 10µ to 15 mS/cm) and a Pt100 measuring insert in two-wire circuit. It is installed via the process connection G 1A made of PVDF. The electrical connection is a device connector in angular design according to DIN 43650. The material of the electrode is graphite, the insertion length is 78 mm. The operating temperature is 0 to +135 °C and the maximum compressive strength is 16 bar at 25 °C as well as 9 bar at 130°C
Merkmale
| Verpackungseinheit | 1 |
| Gewicht | 0,17 |
| Gewichtseinheit | KG |
| Gewichtbezugsmenge | 1 |
| Ausführung | konduktiv |
| Max. Druck | 16 bar |
| Max. Temperatur | 130 °C |
| Ausführung des elektrischen Anschlusses | sonstige |
| Winkelstecker | ja |
| Ausführung des Prozessanschlusses | G 1 Zoll |
| Zellenkonstante | 1 |
| Werkstoff der Elektrode | Graphit |
| Sensortyp | Pt100 |
| Einstecklänge | 78 mm |
| Werkstoff des Prozessanschlusses | Polyvinylidenfluorid (PVDF) |
| Kurzbeschreibung | Conductive 2-electrode conductivity sensor |
| eClass 11.0 - Klasse | 27209090 |
| UNSPSC 14.0801 - Klasse | 41111900 |
